PC4-M6 / Ø4 mm straight push-in quick connector with M6 thread

Name: PC4-M6 / Ø4 mm straight push-in quick connector with M6 thread
SKU: PC4-M6
Price: 375 HUF
Availability: InStock

Ø4 mm straight push-in connector with M6 thread.

The PC4-M6 straight push-in threaded connector is used to connect a plastic (PA, PU, PUR, PE) or teflon tube with an outer diameter of 4 mm and a M6 inner diameter working cylinder or other pneumatic receiving system element. The push-in release ring helps to easily connect or disconnect the tubes by hand - no special tools are required to connect the tubes.
The connector has a brass body with an external and internal hexagon, making it easy to install in tight spaces.
The PC4-M6 quick coupling has a pre-coated teflon thread seal, so it is supplied ready for immediate installation.

Operating medium: compressed air, vacuum
Maximum pressure: 10 bar
Operating temperature: 0°C to +40°C
Thread standard: metric

In stock

295 Ft (Excl. VAT)

Info

Shape

I - Straight

Material

Plastic, Brass

Tube connection

Ø 4 mm

Thread size

Article No.

PC4-M6
